Versatile 610DT

Last Updated: September 2024

Overview

The Versatile 610DT is a powerful articulated crawler tractor built for heavy-duty farm work. It has a Cummins QSX15 diesel engine with 6 cylinders and 605 horsepower, making it one of the strongest tractors in its class. The engine is turbocharged and liquid-cooled, which helps it run smoothly in tough conditions.

This tractor is very heavy, weighing 58,850 pounds, which gives it excellent traction on all types of terrain. It has tracks instead of wheels, which helps it move easily over muddy or uneven ground. The 610DT has a full power shift transmission with 16 forward gears and 4 reverse gears, allowing the driver to choose the right speed for any job. It also has a closed center load sensing hydraulic system, which makes it great for using different attachments.

The Versatile 610DT is packed with features that make it stand out. It has a very high engine displacement, power output, and operating weight compared to other tractors. The wheelbase is 154 inches, and it can handle loads up to 66,900 pounds. With its Tier IV emissions level, it's also designed to be more environmentally friendly. This tractor is perfect for farmers who need a strong, reliable machine for their biggest jobs.
Show more...

Key Specifications

Category: Articulated

Power Output: 605 hp (451.1 kW)

Transmission: Full power shift

Drive Type: Track

Operating Weight: 58850 lb (26694 kg)

Fuel Type: Diesel

Versatile 610DT vs. Similar Tractors

Power Output

The Power Output for the Versatile 610DT is Excellent. It is greater than 95% of similar Articulated tractors in our database.

Horsepower distribution of Articulated tractors

(across 0.0K+ tractors in our database)

Operating Weight

The Operating Weight for the Versatile 610DT is Above Average. It is greater than 72% of similar Articulated tractors in our database.

Operating weight distribution of Articulated tractors

(across 0.0K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Versatile 610DT is Above Average. It is greater than 73% of similar Articulated tractors in our database.

Engine displacement distribution of Articulated tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Versatile 610DT is Below Average. It is greater than 14% of similar Articulated tractors in our database.

Engine rated RPM distribution of Articulated tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Cummins
Model
QSX15
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Fuel Type
Diesel
Induction Type
Turbocharged aftercooled
Cylinders
6
Displacement
912 ci (14.9 L)
Bore
5.39 in (137.0 mm)
Stroke
6.65 in (169.0 mm)
Rated RPM
1800
Power Output
605 hp (451.1 kW)

Transmission

Type
Full power shift
Forward Gears
16
Reverse Gears
4

Drivetrain

Chassis
Crawler
Drive Type
Track
