Versatile 2270

Last Updated: June 2024

Overview

The Versatile 2270 is a robust four-wheel drive tractor, designed to handle a variety of demanding agricultural tasks. It is equipped with a Cummins M11 engine that boasts 6 cylinders, a displacement of 660 cubic inches, and a turbocharged diesel power system. The engine is liquid-cooled and operates at a rated 2100 RPM, producing 270 horsepower. This power is delivered to the ground through a partially synchronized transmission offering 12 forward and 4 reverse gears, ensuring versatility and control during different farming operations. The tractor features articulated power steering for better maneuverability, especially important given the articulated 4WD chassis which can be advantageous in challenging field conditions. The hydraulic system is a closed center load sensing type, which likely contributes to efficient operation under varying loads. While several specifications such as overall dimensions, weight, and specific hitch lift capacity are not detailed, the Versatile 2270's build suggests it can support substantial workloads, making it a substantial asset for modern farming operations.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 270

Transmission: partially synchronized

Drive Type: 4WD

Fuel Type: diesel

Versatile 2270 vs. Similar Tractors

Power Output
Excellent
Greater than 94% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
M11
Cooling Type
liquid-cooled
Cylinder Orientation
inline
Valve Configuration
-
Fuel Type
diesel
Induction Type
turbocharged
Cylinders
6
Displacement (ci)
660
Bore (in)
4.92
Stroke (in)
5.79
Rated RPM
2100
Power Output (hp)
270

Transmission

Type
partially synchronized
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
articulated power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
IVN/III
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
closed center load sensing
