Versatile 2240

Last Updated: June 2024

Overview

The Versatile 2240 is a robust and powerful four-wheel-drive articulated tractor tailored for heavy-duty farming tasks. With a 240 horsepower Cummins C8.3 turbocharged diesel engine, it offers ample power for a variety of applications. The engine, which displaces 505 cubic inches and operates at a rated 2100 RPM, is designed for reliability and efficiency. The liquid-cooled, six-cylinder configuration ensures consistent performance under demanding conditions. A key feature of the Versatile 2240 is the QuadShift III transmission, which provides 12 forward and 4 reverse gears, coupled with the convenience of partial synchronization. The articulated power steering provides improved maneuverability, especially useful in tight turns or working on uneven terrain. The tractor's closed center load sensing hydraulic system is optimized for precision and responsiveness, enhancing overall operational efficiency. As a product of Versatile, a brand known for its dependable and rugged machinery, the 2240 model embodies the qualities necessary for intensive agricultural operations.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 240

Transmission: Partially synchronized

Drive Type: 4WD

Fuel Type: Diesel

Versatile 2240 vs. Similar Tractors

Power Output
Excellent
Greater than 93% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
C8.3
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
505
Bore (in)
4.49
Stroke (in)
5.31
Rated RPM
2100
Power Output (hp)
240

Transmission

Type
Partially synchronized
Forward Gears
12
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
Articulated power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Closed center load sensing
