Valtra T170

Last Updated: September 2024

Overview

The Valtra T170 is a powerful row crop tractor built for tough farm work. It has a strong 4-wheel drive system and a comfortable cab for the driver. The tractor is powered by a Sisu Diesel engine with 6 cylinders and 170 horsepower. This engine is cooled by liquid and uses diesel fuel. It has a turbocharger and intercooler to make it even stronger.

The T170 has a special transmission with 36 forward and 36 reverse gears. This gives the driver lots of choices for different jobs. The tractor has big tires made for farm work, with 16.9R28 in the front and 20.8R38 in the back. It's a big machine, measuring about 203 inches long, 92 inches wide, and 119 inches tall. The tractor weighs 13,118 pounds, which is about average for its size. It has a strong hitch in the back for pulling heavy equipment. The hydraulic system is designed to sense the load, making it easier to use different tools.
Show more...

Key Specifications

Category: Row Crop

Power Output: 170 hp (126.8 kW)

Transmission: 3-speed power shift

Drive Type: 4WD

Operating Weight: 13118 lb (5950 kg)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Sisu Diesel
Model
634 DSRAE
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Intercooled turbocharged
Cylinders
6
Displacement
450 ci (7.4 L)
Bore
4.25 in (108.0 mm)
Stroke
5.28 in (134.0 mm)
Rated RPM
2100
Power Output
170 hp (126.8 kW)

Transmission

Type
3-speed power shift
Forward Gears
36
Reverse Gears
36

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
