Valtra N114

Last Updated: June 2024

Overview

The Valtra N114 is a row-crop tractor known for its impressive blend of power and agility. It is equipped with a liquid-cooled AGCO Power 4-cylinder turbocharged intercooled diesel engine that delivers an output of 114 horsepower and a maximum power of 123.4 hp. The tractor's power plant is robust and operates at a peak torque of 368.8 lb-ft at 1500 RPM, and is designed to meet Stage 4 emissions standards. With its 30 forward gear five-speed power shift transmission, the N114 is well-suited for a variety of farming tasks that require both precision and strength. The tractor operates on a 4x4 MFWD 4WD chassis and is steered via a power steering system. It has an operating weight of 13,448 pounds and a ground clearance of 21.7 inches, which adds to its stability across diverse terrains. With a wheelbase of 104.9 inches and a total length of 183.3 inches, the N114 is designed to provide comfort and control, crucial for long working hours in the field. The tractor's height to the cab is 116.5 inches, offering good visibility for the operator. For further customization or usage needs, details regarding the hydraulic system, hitch categories or signaling additional features remain specific to individual models and configurations.
Show more...

Key Specifications

Category: Row Crop

Power Output: 114

Transmission: Five-speed power shift

Drive Type: 4WD

Operating Weight: 13448

Fuel Type: Diesel

Valtra N114 vs. Similar Tractors

Power Output
Average
Greater than 31% of similar tractors.
Operating Weight
Average
Greater than 54% of similar tractors.

Technical Specifications

Engine

Manufacturer
AGCO Power
Model
44 AWF
Cooling Type
Liquid
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
4
Displacement (ci)
268.4
Bore (in)
4.25
Stroke (in)
4.72
Rated RPM
2100
Power Output (hp)
114

Transmission

Type
Five-speed power shift
Forward Gears
30
Reverse Gears
-
Total Gears
30

Dimensions

Length (in)
183.3
Width (in)
-
Height (in)
116.5 (Height to cab)
Operating Weight (lb)
13448

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
