Valtra 3500

Last Updated: June 2024

Overview

The Valtra 3500 is a compact utility tractor notable for its air-cooled Deutz F4L913 diesel engine, which delivers 76 horsepower and a torque output of 191.8 lb-ft at 1600 RPM. It is equipped with a 24-speed partially synchronized transmission and operates in a 4x2 2WD chassis configuration, featuring power steering for ease of maneuverability. The tractor has a wheelbase of 83.1 inches and offers a choice of tire specifications to suit various agricultural needs from standard farm operations to specialized orchard work. In terms of dimensions, the Valtra 3500 has a length of 153.1 inches, a width of 66.9 inches, and varied height depending on the presence of ROPS or cab. This model's operating weight varies between 5038 to 6096 pounds, suggesting a sturdy build capable of handling diverse tasks. While the starting system is electric, further details about the tractor's hydraulic system and PTO are not specified.

Key Specifications

Category: Utility

Power Output: 76

Transmission: Partially synchronized

Drive Type: 2WD

Operating Weight: 5038 (2WD ROPS), 5523 (2WD Cab), Unknown (operating weight for 4WD as 4WD is not indicated in the specs)

Fuel Type: Diesel

Image Gallery

Valtra 3500 Tractor

Valtra 3500 vs. Similar Tractors

Power Output

Average

Greater than 69% of similar tractors.

Technical Specifications

Engine

Manufacturer: Deutz
Model: F4L913
Cooling Type: Air-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 4
Displacement (ci): 249.3
Bore (in): 4.016
Stroke (in): 4.921
Rated RPM: 2350
Power Output (hp): 76

Transmission

Type: Partially synchronized
Forward Gears: 24
Reverse Gears: 24
Total Gears: -

Dimensions

Length (in): 153.1
Width (in): 66.9
Height (in): 101.4 (with ROPS), 94.1 (with cab)
Operating Weight (lb): 5038 (2WD ROPS), 5523 (2WD Cab), Unknown (operating weight for 4WD as 4WD is not indicated in the specs)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): 16
Front Tire Width (in): -
Rear Tire Diameter (in): 28
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag front: 6.50-16 (2WD), Ag rear: 14.9R28, Ag front: 10.0/75-15.3 (orchard), Ag rear: 360/70-24 (orchard)
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: ROPS
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
