Valtra 3100

Last Updated: June 2024

Overview

The Valtra 3100 is a compact utility tractor that boasts a robust Deutz F3L912 engine. It comes with a 4-wheel drive system and a power steering feature that enhances maneuverability and ease of use for the operator. The 52 horsepower, air-cooled, diesel-fueled engine is capable of 2350 RPM and generates a torque of 125.4 lb-ft at 1600 RPM. This tractor is specifically designed to handle various agricultural tasks with efficiency. Its 24-speed partially synchronized transmission system offers a wide range of speeds suitable for different applications. The tractor's dimensions include a length of 148 inches, width of 66.9 inches, and height varies depending on the presence of a ROPS or cab configuration, measuring at 101.4 inches and 91.3 inches respectively. The tractor is versatile, with tire options accommodating general agriculture and orchard work. Despite its capability, the Valtra 3100 maintains a modest ground clearance of 13.8 inches which allows operation in various terrains while preventing underside damage. Its wheelbase measures 82.5 inches, providing a stable platform for numerous tasks. Weights vary with the ROPS model weighing in at 5159 lbs, and the cab variant at 5644 lbs, indicating that it is a heavy-duty machine within its compact utility class.
Show more...

Key Specifications

Category: Utility

Power Output: 52

Transmission: Partially synchronized

Drive Type: 4WD

Operating Weight: ROPS Weight: 5159, Cab Weight: 5644

Fuel Type: Diesel

Valtra 3100 vs. Similar Tractors

Power Output
Average
Greater than 50% of similar tractors.
Operating Weight
Average
Greater than 44% of similar tractors.

Technical Specifications

Engine

Manufacturer
Deutz
Model
F3L912
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspiration
Cylinders
3
Displacement (ci)
172.5
Bore (in)
3.937
Stroke (in)
4.724
Rated RPM
2350
Power Output (hp)
52

Transmission

Type
Partially synchronized
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
148
Width (in)
66.9
Height (in)
Height (ROPS): 101.4, Height (cab): 91.3
Operating Weight (lb)
ROPS Weight: 5159, Cab Weight: 5644

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
Front: Unknown, Rear: Unknown
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
