Valpadana 6550

Last Updated: June 2024

Overview

The Valpadana 6550 tractor is a 4-wheel drive model equipped with a shuttle/creeper transmission that offers 16-speed gear capabilities for both forward and reverse motion. Its 4-cylinder, 8-valve diesel engine provides a power output of 46 horsepower (34.3 kW) at a rated RPM of 2800, with a torque of 106.2 lb-ft at 1600 RPM and a displacement of 133.6 cubic inches. The cooling system for the engine is liquid-cooled to maintain optimal operating temperatures. This compact tractor's chassis, labeled as 4x4 MFWD 4WD, suggests versatile performance on various terrains, and the tractor's overall dimensions include a length of 127.3 inches, width of 49.8 inches, and height of 50.8 inches, thus supporting maneuverability and accessibility in tighter spaces. The wheelbase of 55 inches aids in stability. Tire information indicates that this model can be equipped with different sizes of agricultural tires to match various agricultural needs or ground conditions. Its operating weight is 3,902 lbs, which indicates its category in the mid-range utility class. Specific details like the starter type, operator station type, and hydraulic system type are yet to be ascertained, necessitating further investigation for owners who require this data for maintenance or operational purposes.
Show more...

Key Specifications

Power Output: 46

Transmission: shuttle/creeper

Drive Type: 4WD

Operating Weight: 3902

Fuel Type: diesel

Technical Specifications

Engine

Manufacturer
Unknown
Model
4TNV88-KVA
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
8-valve
Fuel Type
diesel
Induction Type
-
Cylinders
4
Displacement (ci)
133.6
Bore (in)
-
Stroke (in)
-
Rated RPM
2800
Power Output (hp)
46

Transmission

Type
shuttle/creeper
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
127.3
Width (in)
49.8
Height (in)
50.8
Operating Weight (lb)
3902

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
