Valpadana 1645

Last Updated: June 2024

Overview

The Valpadana 1645 is a multifunctional tractor ideal for a variety of tasks in agriculture or smallholdings. This tractor is equipped with a liquid-cooled diesel engine, Model 4TNE84-ELAN, having a displacement of 121.7 cubic inches and generating 44 horsepower at 2800 RPM. With a multiple transmission option, including shuttle, creeper and even a hydrostatic in an infinite 3-range forward and reverse setup, it not only provides versatility in speed selection but also precise handling for different operations. Additionally, the tractor sports a robust four-wheel-drive system (4x4 MFWD 4WD), further enhancing its capabilities in challenging terrains or during heavy-duty tasks. With an operating weight of 3,483 pounds and ample ground clearance of 14.6 inches, the Valpadana 1645 is designed for reliability and durability. Hence, it meets the demands of its operators who require solid performance combined with simplicity and comfort.
Show more...

Key Specifications

Power Output: 44

Transmission: Shuttle, Creeper, Hydrostatic

Drive Type: 4WD

Operating Weight: 3483

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Unknown
Model
4TNE84-ELAN
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4-cylinder
Displacement (ci)
121.7
Bore (in)
3.307
Stroke (in)
3.543
Rated RPM
2800
Power Output (hp)
44

Transmission

Type
Shuttle, Creeper, Hydrostatic
Forward Gears
-
Reverse Gears
-
Total Gears
12 forward and reverse, 16 forward and reverse, infinite 3-range forward and reverse

Dimensions

Length (in)
134.6
Width (in)
54.33
Height (in)
92
Operating Weight (lb)
3483

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag front: 240/70-16, Ag rear: 360/70-20
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
