Valpadana 1640

Last Updated: June 2024

Overview

The Valpadana 1640 tractor is a versatile and robust machine designed to operate efficiently in a variety of agricultural settings. It is equipped with 4-wheel drive and provides a 37.5 hp power output from a 3-cylinder, liquid-cooled diesel engine. The varied transmission options include a 12-speed shuttle, 16-speed shuttle/creeper, and an infinite 3-range hydrostatic transmission which, combined with its 2800 rated RPM and significant torque of 75.8 lb-ft at an optimal 1800 RPM, offer the user flexibility depending on the task. The tractor supports agricultural tire sizes of 200/70-16 for the front and 320/70-20 for the rear, ensuring ample traction. Overall dimensions of the tractor enable it to operate effectively in different terrains, with ground clearance at 13.4 inches and a weight of 3461 pounds. This establishes the Valpadana 1640 as a substantial workhorse that can handle a variety of agricultural tasks.
Show more...

Key Specifications

Power Output: 37.5

Transmission: Multiple Options (Shuttle, Shuttle/Creeper, Hydrostatic)

Drive Type: 4WD

Operating Weight: 3461

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Unknown
Model
3TNE88-ELAN
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
3
Displacement (ci)
100.2
Bore (in)
3.465
Stroke (in)
3.543
Rated RPM
2800
Power Output (hp)
37.5

Transmission

Type
Multiple Options (Shuttle, Shuttle/Creeper, Hydrostatic)
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
134.6
Width (in)
51.97
Height (in)
90.6
Operating Weight (lb)
3461

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
