Valpadana 1020

Last Updated: June 2024

Overview

The Valpadana 1020 is a compact tractor known for its ease of use and maneuverability, thanks to its mechanical rack steering. With a 16 horsepower Vanguard 2-cylinder air-cooled gasoline engine, it offers a sufficient power-to-size ratio for various small-scale agricultural and maintenance tasks. This model features a hydrostatic transmission with infinite forward and reverse gears, providing smooth control over the tractor's speed and direction. Its versatility is also evident in the different front and rear tire configurations, catering to both agricultural fields and lawn or turf care. Measuring 43 inches long and 30 inches wide, with a height of 41 inches and a weight of 685 pounds, this tractor manages to combine compact dimensions with a solid presence. Ground clearance of 7.1 inches allows for operation over uneven terrain without significant risk of undercarriage damage.
Show more...

Key Specifications

Power Output: 16

Transmission: Hydrostatic

Operating Weight: 685

Fuel Type: Gasoline

Technical Specifications

Engine

Manufacturer
Vanguard
Model
-
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Gasoline
Induction Type
-
Cylinders
2
Displacement (ci)
29.29
Bore (in)
-
Stroke (in)
-
Rated RPM
-
Power Output (hp)
16

Transmission

Type
Hydrostatic
Forward Gears
Infinite
Reverse Gears
Infinite
Total Gears
-

Dimensions

Length (in)
43
Width (in)
30
Height (in)
41
Operating Weight (lb)
685

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Mechanical Rack
Coolant Capacity (qts)
-
Front Tire Diameter (in)
8 (For ag tires), 16 (For lawn/turf tires)
Front Tire Width (in)
4.00 (For ag tires), 6.50 (For lawn/turf tires)
Rear Tire Diameter (in)
12 (For ag tires), 23 (For lawn/turf tires)
Rear Tire Width (in)
6.5 (For ag tires), 8.50 (For lawn/turf tires)
Front/Rear Rim Diameter (in)
-
Tire Type
Ag tires, Lawn/turf tires
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (12 volts starter)
Brake Type
-
Hydraulic System Type
-
