Ursus 4514D

Last Updated: June 2024

Overview

The Ursus 4514D is outfitted with a four-cylinder engine model 4390 which provides 78 hp at 2200 rpm and 61 hp on the PTO. The engine displacement is 235.9 cubic inches. The tractor moves through its tasks using a mechanical transmission with sliding gears, offering 8 forward gears and 2 reverse gears. This utility tractor operates with a weight of 7716.2 pounds and has a tire configuration with front tires measuring 9.5 inches in width and 24 inches in diameter, with rear tires at 16.9 inches wide and 34 inches in diameter. While specific details about the chassis, drive type, and steering system are unknown, the data suggests it is designed for multiple agricultural tasks supported by a lift capacity of 4850.2 lbs at a 24-inch hitch point and a category 2 three-point hitch type. It has a fuel capacity of 21.2 gallons and features like a 55 A alternator, suggesting it is built for sustained operation during demanding fieldwork.
Show more...

Key Specifications

Power Output: 78

Transmission: Mechanical with sliding gears

Operating Weight: 7716.2

Lift Capacity: 4850.2

Technical Specifications

Engine

Manufacturer
Unknown
Model
4390
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
-
Cylinders
4
Displacement (ci)
235.9
Bore (in)
-
Stroke (in)
-
Rated RPM
2200
Power Output (hp)
78

Transmission

Type
Mechanical with sliding gears
Forward Gears
8
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
Incorrect data provided (12.4 inches is unlikely to be the length of a tractor; possibly a typographical error)
Width (in)
79.2
Height (in)
100.8
Operating Weight (lb)
7716.2

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
17.6 (conversion from 4.4 gallons)
Front Tire Diameter (in)
24
Front Tire Width (in)
9.5
Rear Tire Diameter (in)
34
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
2 cat. ISO
Hitch Position
-
Hitch Capacity (lb)
4850.2
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
