Ursus 1614

Last Updated: June 2024

Overview

The Ursus 1614 is a powerful agriculture tractor equipped with a turbocharged Zetor diesel engine model Z8602.1, which delivers a horsepower of 155 and a torque of 392.4 lb-ft at 1600 rpm. This model is built with a four-wheel drive (4WD) chassis and features power steering for easier maneuverability. The tractor's two-speed power-shift transmission provides a total of 18 speeds, with 12 forward and 6 reverse gears, facilitating versatile operations in various farming tasks. The 1614 model has a significant lifting capacity at the hitch with a category III configuration, capable of handling heavy-duty implements. Enclosed in a cab for operator comfort and protection, the tractor comes with a rated 2200 rpm and has an operating weight of 11,091 lbs. With a substantial wheelbase of 106.1 inches and equipped with large tires, front 14.9-24 and rear 18.4-38, it ensures stability and traction across different terrains. Note: The tractor's length, height, and width are provided based on centimeter conversions to inches.
Show more...

Key Specifications

Power Output: 155

Transmission: Two-speed power shift

Drive Type: 4WD

Operating Weight: 11,091

Fuel Type: Diesel

Lift Capacity: 12,125.5 lbs

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z8602.1
Cooling Type
Liquid-cooled
Cylinder Orientation
Vertical
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
417.6
Bore (in)
4.33
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
155

Transmission

Type
Two-speed power shift
Forward Gears
12
Reverse Gears
6
Total Gears
18

Dimensions

Length (in)
180.7
Width (in)
89.4
Height (in)
108.3 (Height of cab)
Operating Weight (lb)
11,091

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 (4WD)
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
30.6
Front Tire Diameter (in)
24
Front Tire Width (in)
-
Rear Tire Diameter (in)
38
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category III
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
12,125.5 lbs
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
