Ursus 1434

Last Updated: June 2024

Overview

The Ursus 1434 is a 4-wheel drive tractor, equipped with a robust power plant manufactured by Zetor - the Z 8701.13 model. This turbocharged, 6-cylinder, liquid-cooled diesel engine provides a significant 136 horsepower, contributing to the tractor's strong performance and suitability for medium to heavy-duty tasks. Displacing 416.4 cubic inches and running at a rated RPM of 2200, the engine uses a direct injection fuel system to efficiently deliver its power. The tractor transfers this power through a manual transmission system that boasts 12 forward and 6 reverse gears, allowing for a wide range of speed options during operation. Power steering enhances the operability and ease of use for the tractor, ensuring that users can navigate challenging terrain and long working hours with less effort. Though many aspects of the tractor remain unspecified, it's clear that the Ursus 1434 is designed to handle demanding agricultural tasks. The chassis configuration, marked as 4x4 MFWD 4WD, denotes that this tractor is well-suited to a variety of ground conditions, providing good traction and stability. The presence of a three-point hitch (Category 3) highlights its capability to work with a wide assortment of attachments, though the specific hitch lift capacity is not provided.
Show more...

Key Specifications

Power Output: 136

Transmission: Manual

Drive Type: 4WD

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Zetor
Model
Z 8701.13
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
416.4
Bore (in)
4.33
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
136

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
6
Total Gears
18

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
