TYM TX853

Last Updated: June 2024

Overview

The TYM TX853 is a utility tractor equipped with a 4WD chassis and hydrostatic power steering, enhancing its maneuverability across various terrains. It is powered by a Cummins B3.3 turbocharged diesel engine capable of delivering 85 horsepower and a displacement of 199 cubic inches. The engine operates at a rated RPM of 2600 and is kept cool using a liquid-cooling system. The tractor's transmission system boasts a comprehensive set of 24 forward and reverse gears, though the exact type of transmission is not specified. Offering a sturdy and robust frame, the TX853 measures 155.1 inches in length, has a width of 76.4 inches, and attains a height of 106.7 inches when equipped with a cab. It has a substantial operating weight of 6757 pounds, indicating a well-built machine designed to handle demanding utility tasks. The tractor is also classified with a Category 3 hitch, and it comes with an electric starter system. The exact year of manufacture, hitch lift capacity, PTO specifications, and hydraulic system type remain unspecified, requiring users to refer to their owner's manual or contact TYM directly for further details.
Show more...

Key Specifications

Category: Utility

Power Output: 85

Drive Type: 4WD

Operating Weight: 6757

Fuel Type: Diesel

TYM TX853 vs. Similar Tractors

Power Output
Above Average
Greater than 74% of similar tractors.
Operating Weight
Average
Greater than 51% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
B3.3
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
199
Bore (in)
3.74
Stroke (in)
4.53
Rated RPM
2600
Power Output (hp)
85

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
155.1
Width (in)
76.4
Height (in)
106.7 (Assuming this is the height with the cab as no other value is provided)
Operating Weight (lb)
6757

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab (Assuming since height is given with 'cab')
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
