TYM TX753

Last Updated: June 2024

Overview

The TYM TX753 is a utility tractor known for its robust build and Cummins B3.3 turbocharged diesel engine. Equipped with a full-time 4WD (4x4 MFWD 4WD) and a hydrostatic power steering system, the TX753 offers excellent maneuverability and handling. The tractor comes with a 24-speed transmission, providing ample gear choices for various tasks. The 75 horsepower engine operates at a rated RPM of 2600, making it capable of handling a diverse range of agricultural tasks. Liquid-cooled for efficient thermal regulation, the Cummins engine ensures reliable performance. The tractor has a substantial length of 155.1 inches, a width of 76.4 inches, and a cab height of 106.7 inches, with an operating weight of 6757 lbs, indicating a solid and stable workhorse suited for various farming operations.
Show more...

Key Specifications

Category: Utility

Power Output: 75

Drive Type: 4WD

Operating Weight: 6757

Fuel Type: Diesel

TYM TX753 vs. Similar Tractors

Power Output
Average
Greater than 68% of similar tractors.
Operating Weight
Average
Greater than 51% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
B3.3
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
199
Bore (in)
3.74
Stroke (in)
4.53
Rated RPM
2600
Power Output (hp)
75

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
48

Dimensions

Length (in)
155.1
Width (in)
76.4
Height (in)
106.7
Operating Weight (lb)
6757

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
