TYM TL493

Last Updated: June 2024

Overview

The TYM TL493 is a compact utility tractor that is well suited for a variety of tasks around the small farm, estate, or commercial landscaping. This tractor features a robust 49 horsepower Yanmar diesel engine that delivers reliable power and a liquid-cooled system to maintain performance over long work periods. It has a 4-wheel drive chassis with a mechanical front wheel drive (MFWD), providing excellent traction in diverse conditions. Hydrostatic power steering enhances maneuverability with ease, especially in tight spaces. A notable aspect of the TL493 is its 16-speed transmission, allowing for a wide range of speed options when performing various tasks. The tractor measures 122.8 inches in length, 59.4 inches in width, and carries a height of 97.8 inches, with a protective Roll-Over Protection System (ROPS) installed. The traction is facilitated by standard agricultural tires with a front diameter of 16 inches and a rear diameter of 24 inches. A Category 3 rear hitch provides capability for a range of attachments and implements to be used with the tractor.
Show more...

Key Specifications

Category: Utility

Power Output: 49

Drive Type: 4WD

Fuel Type: Diesel

TYM TL493 vs. Similar Tractors

Power Output
Average
Greater than 47% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
121.7
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
49

Transmission

Type
-
Forward Gears
16
Reverse Gears
-
Total Gears
16

Dimensions

Length (in)
122.8
Width (in)
59.4
Height (in)
97.8
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
16
Front Tire Width (in)
8
Rear Tire Diameter (in)
24
Rear Tire Width (in)
12.4
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
