TYM T552

Last Updated: June 2024

Overview

The TYM T552 is a utility tractor built for a wide range of tasks across different environments. With a robust 4-wheel drive configuration and hydrostatic power steering, it offers reliable traction and maneuverability. It's powered by a John Deere 3029D diesel engine with a displacement of 179 cubic inches, rated at 55 horsepower and operating at a max RPM of 2500. The tractor is equipped with an unspecified transmission type providing 24 forward and reverse gears. Additional specs include a liquid-cooling system, an electric starter, and a weight of 5952 pounds, which showcase its capability to handle demanding tasks. The tractor's dimensions, with a length of 158.7 inches, a width of 70.9 inches, and a height of 97.6 inches with the ROPS installed, point to a relatively compact size, making it suitable for various applications where space can be a constraint.
Show more...

Key Specifications

Category: Utility

Power Output: 55

Drive Type: 4WD

Operating Weight: 5952

Fuel Type: Diesel

TYM T552 vs. Similar Tractors

Power Output
Average
Greater than 53% of similar tractors.
Operating Weight
Average
Greater than 48% of similar tractors.

Technical Specifications

Engine

Manufacturer
John Deere
Model
3029D
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
179
Bore (in)
4.19
Stroke (in)
4.33
Rated RPM
2500
Power Output (hp)
55

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
158.7
Width (in)
70.9
Height (in)
97.6 (ROPS)
Operating Weight (lb)
5952

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural (Assumption based on "Ag front" and "Ag rear" tire information)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS (based on "Height (ROPS)")
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
