TYM T431

Last Updated: June 2024

Overview

The TYM T431 is a tractor designed with a focus on utility and functionality, powered by a robust 43 hp Kubota V2203 diesel engine. It features a synchromesh transmission with 16 forward and reverse gears, which is indicative of its capability to handle a variety of tasks. The tractor is equipped with a power steering system, improving maneuverability and ease of operation. The dry disc clutch is durable and likely contributes to smoother gear transitions. It boasts a wheelbase of 75 inches, ensuring stability in various working conditions. With its notable electric starter, operation is more convenient and reliable. The operating weight of the tractor is 5073 lbs, which underscores its substantial build, suitable for a range of agricultural applications. While specific details on the tractor's hydraulics, PTO, and hitch capabilities are not provided, its dimensions and other known features suggest it is well-suited for small to mid-sized farming tasks. Its ample ground clearance of 13 inches allows for operation over uneven terrain. Dimensions such as a length of 141 inches, width of 63 inches, and a height of 96 inches with a cab show that this tractor is designed to provide a comfortable yet efficient working environment for the operator.
Show more...

Key Specifications

Power Output: 43

Transmission: Synchromesh

Operating Weight: 5073

Fuel Type: Diesel

Image Gallery

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2203
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.4
Stroke (in)
3.6
Rated RPM
2600
Power Output (hp)
43

Transmission

Type
Synchromesh
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
141
Width (in)
63
Height (in)
96 (with cab)
Operating Weight (lb)
5073

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agriculture
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab (assumed as Height is specified with cab)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
