TYM T430

Last Updated: September 2024

Overview

The TYM T430 is a versatile tractor designed for various farming tasks. It features a powerful Kubota V2203 engine, which is a 4-cylinder, liquid-cooled diesel engine. This engine produces 43 horsepower, making it suitable for medium-sized farms and agricultural operations. The tractor has a naturally aspirated engine with a displacement of 134.1 cubic inches, providing reliable performance for everyday use.

One of the standout features of the T430 is its transmission system. It comes with a synchromesh transmission that offers 16 forward and 16 reverse gears, giving operators plenty of options for different tasks and terrains. The tractor is equipped with power steering, making it easy to maneuver in tight spaces. With dimensions of 132 inches in length, 60 inches in width, and 88 inches in height, the T430 is compact enough for various farm applications. It has an operating weight of 3741 pounds and comes with a ROPS (Roll-Over Protective Structure) for operator safety. Additional features include 24-inch rear tires, a 71-inch wheelbase, and 14 inches of ground clearance, making it well-suited for rough terrain and diverse farming conditions.
Show more...

Key Specifications

Power Output: 43 hp (32.1 kW)

Transmission: Synchromesh

Operating Weight: 3741 lb (1697 kg)

Fuel Type: Diesel

TYM T430 vs. Similar Tractors

Power Output

The Power Output for the TYM T430 is Average. It is greater than 35% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 2.6K+ tractors in our database)

Operating Weight

The Operating Weight for the TYM T430 is Below Average. It is greater than 29% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 2.6K+ tractors in our database)

Engine Displacement

The Engine Displacement for the TYM T430 is Below Average. It is greater than 30% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the TYM T430 is Above Average. It is greater than 80% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2203
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement
134 ci (2.2 L)
Bore
3.40 in (86.4 mm)
Stroke
3.60 in (91.4 mm)
Rated RPM
2600
Power Output
43 hp (32.1 kW)

Transmission

Type
Synchromesh
Forward Gears
16
Reverse Gears
16
