TYM T293

Last Updated: June 2024

Overview

The TYM T293 is a compact utility tractor that offers a blend of power and versatility in its class. It comes equipped with a hydrostatic power steering system and a hydrostatic transmission with an infinite (2-range) gear setup, which contributes to its ease of use and adaptability for a variety of tasks. The engine, a Mitsubishi S3L2, is a 3-cylinder, liquid-cooled diesel unit with an 80.4 cubic inch displacement that outputs 29 horsepower. This makes it capable for a wide range of utility jobs. At the rear, the tractor supports a Category I hitch with an unknown lift capacity. The industrial-type tires and 4x4 MFWD 4WD chassis provide stability and traction across various terrain types. The T293 measures 107.8 inches in length, 56.3 inches in width, and stands 91.7 inches tall with the ROPS. The operating weight is listed at 1980 lbs, providing a stable platform for work. This tractor is suitable for small-scale farming, landscaping, and general maintenance tasks around properties.
Show more...

Key Specifications

Category: Utility

Power Output: 29 hp

Transmission: hydrostatic

Operating Weight: 1980 lbs

Fuel Type: diesel

TYM T293 vs. Similar Tractors

Power Output
Below Average
Greater than 23% of similar tractors.
Operating Weight
Below Average
Greater than 16% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S3L2
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
indirect injection
Cylinders
3-cylinder
Displacement (ci)
80.4
Bore (in)
-
Stroke (in)
-
Rated RPM
2800
Power Output (hp)
29 hp

Transmission

Type
hydrostatic
Forward Gears
-
Reverse Gears
-
Total Gears
infinite (2-range)

Dimensions

Length (in)
107.8 in
Width (in)
56.3 in
Height (in)
91.7 in with ROPS
Operating Weight (lb)
1980 lbs

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
-
Steering Type
hydrostatic power
Coolant Capacity (qts)
9.3 qts
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Industrial
Manufacture - End Year
-
Hitch Type
Cat I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
dual gear pump
