TYM T224

Last Updated: September 2024

Overview

The TYM T224 is a compact utility tractor designed for small farms and landscaping tasks. It's powered by a Yanmar 3TNM74F diesel engine with three cylinders and 21.5 horsepower. This engine is liquid-cooled and uses indirect injection for fuel delivery. While the engine's power is below average compared to other tractors, it runs at a very high 3200 RPM, which helps it perform well for its size.

This tractor features a hydrostatic transmission with infinite forward and reverse gears, making it easy to operate. It has power steering for better control and a three-point hitch at the rear, which is useful for attaching various implements. The T224 is quite small, measuring 94.2 inches long, 44.5 inches wide, and 86.6 inches tall. Its light weight of 1433 pounds makes it easy to maneuver in tight spaces. The tractor comes with a ROPS (Roll-Over Protective Structure) for operator safety and uses an open center hydraulic system for smooth operation of attachments.
Show more...

Key Specifications

Category: Utility

Power Output: 22 hp (16.0 kW)

Transmission: Hydrostatic

Operating Weight: 1433 lb (650 kg)

Fuel Type: Diesel

TYM T224 vs. Similar Tractors

Power Output

The Power Output for the TYM T224 is Below Average. It is greater than 11% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the TYM T224 is Poor. It is greater than 5% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the TYM T224 is Poor. It is greater than 6% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the TYM T224 is Excellent. It is greater than 99% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Yanmar
Model
3TNM74F
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Indirect injection
Cylinders
3
Displacement
61 ci (1.0 L)
Bore
2.91 in (73.9 mm)
Stroke
3.03 in (77.0 mm)
Rated RPM
3200
Power Output
22 hp (16.0 kW)

Transmission

Type
Hydrostatic
Forward Gears
Infinite
Reverse Gears
Infinite
