Toro LX426

Last Updated: June 2024

Overview

The Toro LX426 is a 2WD lawn tractor from the LX series. Manufactured by MTD for Toro, the LX426 features a Briggs & Stratton Intek 331777 engine, which is a single-cylinder, natural aspirated gasoline engine with a displacement of 30.6 cubic inches. It generates 20 horsepower and is paired with a mechanical CVT transmission providing infinite forward and reverse gears. Designed for lawn maintenance, the LX426 incorporates a simple open operator station, manual steering, and dry disc brakes, as well as lawn/turf tires suitable for the intended usage. The overall dimensions and lightweight nature allow for easy maneuverability and storage.

Key Specifications

Category: Lawn and Garden

Power Output: 20

Transmission: Mechanical CVT

Drive Type: 2WD

Operating Weight: 498

Fuel Type: Gasoline

Image Gallery

Toro LX426 Tractor

Toro LX426 vs. Similar Tractors

Power Output

Average

Greater than 69% of similar tractors.

Operating Weight

Below Average

Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer: Briggs & Stratton
Model: Intek 331777
Cooling Type: Air-cooled
Cylinder Orientation: Vertical
Valve Configuration: -
Fuel Type: Gasoline
Induction Type: Naturally aspirated
Cylinders: 1
Displacement (ci): 30.6
Bore (in): 3.57
Stroke (in): 3.06
Rated RPM: -
Power Output (hp): 20

Transmission

Type: Mechanical CVT
Forward Gears: Infinite
Reverse Gears: Infinite
Total Gears: -

Dimensions

Length (in): 68
Width (in): 45
Height (in): 42.9
Operating Weight (lb): 498

Power Take-Off (PTO)

PTO Type: Independent with manual clutch
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Manual
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): 6
Rear Tire Diameter (in): -
Rear Tire Width (in): 8
Front/Rear Rim Diameter (in): -
Tire Type: Lawn/turf
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: Open
Starter Type: Electric
Brake Type: Dry disc
Hydraulic System Type: -
