Steyr 8320

Last Updated: June 2024

Overview

The Steyr 8320 tractor is a robust and powerful machine designed with a 4x4 MFWD 4WD chassis, indicating it's capable of handling a variety of tasks on various terrains. This tractor is powered by a 280 hp Steyr WD 615.85 turbo diesel 6-cylinder engine, with a significant torque of 819 lb-ft at 1500 RPM, suited for heavy-duty applications. It operates with a hydrostatic transmission offering infinite forward and reverse gears, giving the operator excellent control over tractor movement. With a wheelbase of 93.3 inches and a hydrostatic power steering system, maneuvering and handling are enhanced for precision work. Its substantial weight of 11,356 lbs underpins the tractor's suitability for carrying out hefty operations reliably. The tire specifications with agricultural treads are 14.5-20 for the front and 18.4-30 for the rear, contributing to the tractor's stability and traction.
Show more...

Key Specifications

Power Output: 280

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 11356

Fuel Type: Turbo Diesel

Technical Specifications

Engine

Manufacturer
Steyr
Model
WD 615.85
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbo Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
593.5
Bore (in)
4.96
Stroke (in)
5.12
Rated RPM
2400
Power Output (hp)
280

Transmission

Type
Hydrostatic
Forward Gears
Infinite
Reverse Gears
Infinite
Total Gears
-

Dimensions

Length (in)
179.9
Width (in)
-
Height (in)
128
Operating Weight (lb)
11356

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
