Steyr 8300

Last Updated: June 2024

Overview

The Steyr 8300 is equipped with a 2WD chassis and operates on a turbocharged diesel engine, model WD 615.84. Featuring a hydrostatic transmission with infinite forward and reverse gears, it provides a versatile and responsive driving experience. The tractor boasts a substantial power output of 260 hp at a rated RPM of 2400, and it is designed to handle a variety of agricultural tasks efficiently. The engine displacement is a notable 593.5 cubic inches with a bore and stroke measuring 4.96 and 5.12 inches, respectively. Additionally, the tractor has a significant operating weight of 11,135 lbs, and its dimensions underscore its robust build, with a length of 180.3 inches and height of 127.6 inches. This model operates with hydrostatic power steering for better maneuverability and ease of control in different farming conditions. Tire options indicate its agricultural application, further confirmed by the wheel size specifications: 12.5/80-18 for the front and 18.4-30 for the rear.
Show more...

Key Specifications

Power Output: 260

Transmission: Hydrostatic

Drive Type: 2WD

Operating Weight: 11,135

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Steyr
Model
WD 615.84
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
593.5
Bore (in)
4.96
Stroke (in)
5.12
Rated RPM
2400
Power Output (hp)
260

Transmission

Type
Hydrostatic
Forward Gears
Infinite
Reverse Gears
Infinite
Total Gears
-

Dimensions

Length (in)
180.3
Width (in)
-
Height (in)
127.6
Operating Weight (lb)
11,135

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
