Steyr 6175 CVT

Last Updated: June 2024

Overview

The Steyr 6175 CVT is a utility tractor known for its powerful Sisu 6-cylinder turbocharged intercooled diesel engine featuring a 402.8 cubic inch displacement and providing a rated power of 175 horsepower which can boost up to 200 horsepower under certain conditions. The engine operates optimally between 1800-2100 RPM with a peak torque of 549.5 lb-ft at 1400 RPM, catering to demanding tasks. The tractor employs a continuously variable transmission (CVT) with infinite forward and reverse gears, allowing for precise speed control and efficient power use. Its 4-wheel drive chassis with front and rear tire formats of 540/65 R30 and 650/65 R42 respectively, supports a wide range of agricultural applications. The tractor's dimensions are 188 inches in length, 100.4 inches in width, and 119.8 inches in height, with an operating weight of 14925 lbs. The wheelbase of 111.5 inches ensures stability on various terrains. The farming community values the 6175 CVT for its combination of size, power, and adaptability to varied agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 175 (Rated) / 200 (Maximum)

Transmission: Continuously variable transmission (CVT)

Drive Type: 4WD

Operating Weight: 14925

Fuel Type: Diesel

Steyr 6175 CVT vs. Similar Tractors

Power Output
Excellent
Greater than 99% of similar tractors.
Operating Weight
Average
Greater than 68% of similar tractors.

Technical Specifications

Engine

Manufacturer
Sisu
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
6
Displacement (ci)
402.8
Bore (in)
4.25
Stroke (in)
4.72
Rated RPM
2100
Power Output (hp)
175 (Rated) / 200 (Maximum)

Transmission

Type
Continuously variable transmission (CVT)
Forward Gears
Infinite
Reverse Gears
Infinite
Total Gears
-

Dimensions

Length (in)
188
Width (in)
100.4
Height (in)
119.8
Operating Weight (lb)
14925

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
30 (Front) / 42 (Rear)
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
III/II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (Assuming "negative" refers to electrical grounding)
Brake Type
-
Hydraulic System Type
-
