Steyr 4095 Multi

Last Updated: June 2024

Overview

The Steyr 4095 Multi is a 4WD utility tractor designed for versatile agricultural tasks. Powered by an Iveco 4-cylinder turbocharged intercooled diesel engine, it has a displacement of 207.5 cubic inches and outputs 99 horsepower at 2200 RPM, with a torque rating of 300 lb-ft at 1500 RPM. This tractor employs a 32-speed four-speed power shift transmission. It's equipped with power steering and a liquid-cooled engine system, offering both reliability and comfort with a cab operator station. The tractor has a rugged chassis, a wheelbase of 95.3 inches, and an operating weight of 9921 lbs. With a ground clearance of 18.1 inches, it is capable of handling varied terrain. Its dimensions are 173.4 inches in length and 82.7 inches in width, with a cab height of 107.3 inches. It can handle a maximum capacity of 16535 lbs.

Key Specifications

Category: Utility

Power Output: 99

Transmission: Power shift

Drive Type: 4WD

Operating Weight: 9921

Fuel Type: Diesel

Image Gallery

Steyr 4095 Multi Tractor

Steyr 4095 Multi vs. Similar Tractors

Power Output

Above Average

Greater than 81% of similar tractors.

Hitch Capacity

Excellent

Greater than 90% of similar tractors.

Operating Weight

Average

Greater than 62% of similar tractors.

Technical Specifications

Engine

Manufacturer: Iveco
Model: -
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged intercooled
Cylinders: 4
Displacement (ci): 207.5
Bore (in): 3.9
Stroke (in): 4.33
Rated RPM: 2200
Power Output (hp): 99

Transmission

Type: Power shift
Forward Gears: 32
Reverse Gears: 32
Total Gears: -

Dimensions

Length (in): 173.4
Width (in): 82.7
Height (in): 107.3
Operating Weight (lb): 9921

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Agricultural
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): 16535
Operator Station Type: Cab
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Open center
