Steyr 370 Kompakt

Last Updated: June 2024

Overview

The Steyr 370 Kompakt is a utility tractor, designed to meet the varied needs of medium-scale farming operations. With its 4-wheel drive and hydrostatic power steering, this model offers improved traction and maneuverability across various terrains. Under the hood, it is powered by an Iveco 8035 turbocharged diesel engine, with 3 cylinders and a displacement of 178.8 cubic inches, generating 72 horsepower and a torque of 157.8 lb-ft at 1400 RPM. The liquid-cooled engine maintains optimal temperatures during prolonged use. The tractor's transmission offerings include the STEYR Synchro Shift and STEYR Power-2 options, allowing up to 32 forward and 16 reverse gears, catering to various speed and power requirements. The 370 Kompakt strikes a balance between power and agility, with its moderate dimensions of 135.4 inches in length and 90.5 inches in width, supporting a total operating weight of 6,283 pounds. Additional details regarding tire sizes, hydraulic system, PTO specifics, and hitch capabilities remain unspecified, but it's notable for adhering to Tier II emissions standards.
Show more...

Key Specifications

Category: Utility

Power Output: 72

Transmission: STEYR Synchro Shift, STEYR Power-2

Drive Type: 4WD

Operating Weight: 6283

Fuel Type: Diesel

Steyr 370 Kompakt vs. Similar Tractors

Power Output
Average
Greater than 65% of similar tractors.
Operating Weight
Average
Greater than 49% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iveco
Model
8035
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
178.8
Bore (in)
4.09
Stroke (in)
4.53
Rated RPM
2300
Power Output (hp)
72

Transmission

Type
STEYR Synchro Shift, STEYR Power-2
Forward Gears
32
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
135.4
Width (in)
90.5
Height (in)
-
Operating Weight (lb)
6283

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
