Steiger Panther IV CM-360

Last Updated: July 2024

Overview

The Steiger Panther IV CM-360 is a large, powerful 4-wheel drive tractor designed for heavy-duty farming tasks. It features an articulated chassis and a 4WD system for improved maneuverability and performance in various field conditions. The tractor is powered by a Caterpillar 3406 turbocharged and aftercooled diesel engine, producing 324.32 hp at 1899 rpm. The transmission is a 20-speed constant mesh with 4 reverse gears. The tractor has a static weight of 29,925 lb without ballast and can reach up to 33,740 lb with ballast. It's equipped with 23.1-34 tires front and rear, with adjustable tread width from 79" to 136.3". The hydraulic system features a direct engine drive with a maximum pressure of 2400 psi and a lift capacity of 13,320 lbs. The tractor's performance was thoroughly tested, showing impressive drawbar capabilities and fuel efficiency across various operating conditions.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 324.32

Transmission: Constant mesh

Drive Type: 4WD

Operating Weight: 29925

Fuel Type: Diesel

Image Gallery

Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor Steiger Panther IV CM-360 Tractor

Steiger Panther IV CM-360 vs. Similar Tractors

Power Output
Excellent
Greater than 96% of similar tractors.
Operating Weight
Above Average
Greater than 72% of similar tractors.

Technical Specifications

Engine

Manufacturer
Caterpillar
Model
3406
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged aftercooled
Cylinders
6
Displacement (ci)
893
Bore (in)
5.4
Stroke (in)
6.5
Rated RPM
2100
Power Output (hp)
324.32

Transmission

Type
Constant mesh
Forward Gears
20
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
253.6
Width (in)
96
Height (in)
-
Operating Weight (lb)
29925

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
Articulated power
Coolant Capacity (qts)
70
Front Tire Diameter (in)
34
Front Tire Width (in)
-
Rear Tire Diameter (in)
34
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (12 volts)
Brake Type
-
Hydraulic System Type
Direct engine drive

Test Results

Nebraska Tractor Test Laboratory - Test Date: October 13 to 24, 1984

Maximum Power and Fuel Consumption

  • Maximum Power: 324.32 hp (241.85 kW) at 1899 rpm
  • Fuel Consumption at Maximum Power: 19.805 Gal/hr (74.970 l/h) with a fuel efficiency of 0.426 lb/hp.hr (0.259 kg/kW.h)
  • Drawbar Pull at Maximum Power: 20162 lbs (89.68 kN)

Drawbar Performance

  • Power at Rated Engine Speed (10th Gear): 315.12 hp (234.99 kW) with a drawbar pull of 17573 lbs (78.17 kN) at a speed of 6.72 mph (10.82 km/h)
  • 75% of Pull at Maximum Power (10th Gear, Ten Hours): 255.29 hp (190.37 kW) with a drawbar pull of 13571 lbs (60.37 kN) and a speed of 7.05 mph (11.35 km/h)
  • 50% of Pull at Maximum Power (10th Gear, Two Hours): 171.96 hp (128.23 kW) with a drawbar pull of 8967 lbs (39.88 kN) and a speed of 7.19 mph (11.57 km/h)

Hydraulic Performance

  • Observed Maximum Pressure: 2400 psi (16550 kPa)
  • Lift Capacity (Maximum Lift Capacity for Transport): 13320 lbs (6042 kg)
  • Hydraulic Oil Temperature: 123 °F (51 °C)

Sound Level

  • Sound Level at Max Power (2100 rpm): 78.5 dB(A)
  • Sound Level at 75% Pull at Max Power: 79.0 dB(A)
  • Sound Level at 50% Pull at Max Power: 78.5 dB(A)
  • Sound Level for Bystander (19th Gear): 102.0 dB(A)

Fuel, Oil, and Time

  • Fuel Type: No. 2 Diesel, Cetane No. 46.8
  • Specific Gravity: 0.8375 (converted to 60/60°F (15/15°C))
  • Oil Classification: SAE 10W-30 API SE-SE, CC-CD
  • Total Engine Operation Time: 38.0 hours
