Steiger Panther III PTA-297

Last Updated: June 2024

Overview

The Steiger Panther III PTA-297 is a robust four-wheel drive, articulated tractor well suited for heavy-duty farming applications. It boasts a significant power output with its turbocharged diesel Cummins VT-903 engine, capable of delivering 295 horsepower with a displacement of 903 cubic inches. The tractor is equipped with an 8-speed power shift transmission with a torque converter, facilitating smooth shifting and efficient power transfer across a range of working conditions. With a large operating weight of 28,975 pounds and a wheelbase measuring 132.5 inches, the Panther III PTA-297 provides a stable and strong platform for a variety of tasks. The specified tire size of 24.5x32 inches supports the machine's hefty frame and work ethic on the field. Although the tractor is sizable, with a length of 264.6 inches and a width of 99 inches, the articulated power steering helps to navigate and maneuver large expanses or tighter spaces that heavy machinery might face. The large hood and exhaust dimensions accentuate its overall heft and presence.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 295

Transmission: power shift

Drive Type: 4WD

Operating Weight: 28975

Fuel Type: diesel

Steiger Panther III PTA-297 vs. Similar Tractors

Power Output
Excellent
Greater than 94% of similar tractors.
Operating Weight
Above Average
Greater than 72% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
VT-903
Cooling Type
liquid-cooled
Cylinder Orientation
V8
Valve Configuration
-
Fuel Type
diesel
Induction Type
turbocharged
Cylinders
8
Displacement (ci)
903
Bore (in)
5.5
Stroke (in)
4.75
Rated RPM
2600
Power Output (hp)
295

Transmission

Type
power shift
Forward Gears
8
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
264.6
Width (in)
99
Height (in)
-
Operating Weight (lb)
28975

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
articulated power
Coolant Capacity (qts)
68
Front Tire Diameter (in)
24.5
Front Tire Width (in)
-
Rear Tire Diameter (in)
24.5
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Three-Point Hitch (Category III assumed based on rear type III*)
Hitch Category
3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter (assuming from Engine - Starter volts: 12)
Brake Type
-
Hydraulic System Type
open center load sensing
