Steiger Lion 1000

Last Updated: June 2024

Overview

The Steiger Lion 1000 is a formidable articulated four-wheel drive (4WD) tractor, identified for its significant power output and robust build. It stands out with an engine power rating of 375 horsepower and a considerable torque of 1266 lb-ft, ideal for heavy-duty tasks on large-scale farming operations. The tractor operates on a full power shift transmission with 12 forward and 2 reverse gears. The chassis configuration, a 4x4 articulated 4WD system accompanied by hydrostatic power steering, ensures efficient maneuverability and power distribution. At a substantial operating weight of 29,000 lbs and a wheelbase of 141.5 inches, the Steiger Lion 1000 exhibits stability in challenging field conditions. It is also equipped with a hydraulic wet disc clutch and a closed center load sensing pressure-compensating hydraulic system. Although the narrative focuses on the functionality of the Lion 1000, potential operators might seek information about hitch type, PTO options, and brake system specifications, which are currently unspecified.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 375

Transmission: Full power shift

Drive Type: 4WD

Operating Weight: 29000

Fuel Type: Diesel

Steiger Lion 1000 vs. Similar Tractors

Power Output
Excellent
Greater than 96% of similar tractors.
Operating Weight
Above Average
Greater than 72% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins and Caterpillar
Model
Cummins: 14.0L 6-cyl diesel, Caterpillar: 14.6L 6-cyl diesel
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspiration
Cylinders
6
Displacement (ci)
893
Bore (in)
5.5
Stroke (in)
6
Rated RPM
2100
Power Output (hp)
375

Transmission

Type
Full power shift
Forward Gears
12
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
281
Width (in)
44 (frame width)
Height (in)
149.6 (height to exhaust)
Operating Weight (lb)
29000

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
81.2
Front Tire Diameter (in)
24.5
Front Tire Width (in)
-
Rear Tire Diameter (in)
24.5
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
IV*
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
Closed center load sensing pressure compensating
