Steiger Cougar IV KS-280

Last Updated: June 2024

Overview

The Steiger Cougar IV KS-280 is a four-wheel drive (4WD) tractor that caters to the heavy-duty needs of large scale farming and land management. At its core, it houses a robust Cummins NT-855 engine which is a turbocharged, 6-cylinder, liquid-cooled diesel engine with a displacement of 855 cubic inches, indicating a significant power capability. Equipped with a 10-speed Spicer transmission that includes 10 forward and 2 reverse gears, this tractor is designed to handle a variety of tasks efficiently. The power output of the engine is rated at 280 horsepower, which ensures substantial performance for demanding operations. The chassis is configured as 4x4 4WD, pointing towards its ability to navigate and operate in challenging terrain with increased traction and stability. Missing specific data on components and features like PTO, hydraulics, and dimensions implies that potential users would need to consult the original documentation or a dealer for further details. The lack of exact information on tire sizes, hitch type, and lift capacity suggests a spectrum of configurations that could be offered by Steiger for this model, tailored to different farming requirements or regional specifications.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 280

Drive Type: 4WD

Fuel Type: Diesel

Steiger Cougar IV KS-280 vs. Similar Tractors

Power Output
Excellent
Greater than 94% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
NT-855
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
855
Bore (in)
5.5
Stroke (in)
6
Rated RPM
-
Power Output (hp)
280

Transmission

Type
-
Forward Gears
10
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
