Steiger 9180

Last Updated: June 2024

Overview

The Steiger 9180 is a powerful, 4-wheel drive tractor designed for heavy-duty agricultural tasks. Outfitted with a large, liquid-cooled, Cummins NTA-855 engine, this tractor delivers a robust 375 horsepower, suitable for pulling heavy implements and performing in varied and challenging field conditions. The 9180 features a hydrostatic power steering system, allowing for more precise control and maneuverability. The chassis is a 4x4 articulated 4WD construction which provides enhanced traction and stability on uneven terrain. The tractor’s 12-speed fully power-shift transmission ensures smooth transmission of power, with the right balance and efficiency for different operations. With an imposing presence, the 9180 is 279.5 inches in length and has a minimum width of 92.3 inches, which can expand to 163.9 inches with dual tires. The tractor stands tall at an exhaust height of 149.6 inches and is quite hefty at an operating weight of 28,000 lbs, underscoring its durability and capacity to handle substantial workloads. The large frame and ground clearance of 19.5 inches underline its capability in a range of field conditions.
Show more...

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 375

Transmission: full power shift

Drive Type: 4WD

Operating Weight: 28000

Fuel Type: diesel

Steiger 9180 vs. Similar Tractors

Power Output
Excellent
Greater than 96% of similar tractors.
Operating Weight
Above Average
Greater than 72% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
NTA-855
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
turbocharged intercooled
Cylinders
6
Displacement (ci)
855
Bore (in)
5.5
Stroke (in)
6
Rated RPM
2100
Power Output (hp)
375

Transmission

Type
full power shift
Forward Gears
12
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
279.5
Width (in)
Minimum: 92.3 / Duals: 163.9
Height (in)
149.6 (exhaust)
Operating Weight (lb)
28000

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 articulated 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
66
Front Tire Diameter (in)
24.5
Front Tire Width (in)
-
Rear Tire Diameter (in)
24.5
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
electric (12 volts)
Brake Type
-
Hydraulic System Type
closed center
