Sonalika DI-90

Last Updated: June 2024

Overview

The Sonalika DI-90 is a diesel-powered tractor designed for a variety of agricultural tasks. It's powered by a 210.9 cubic inch, 4-cylinder, liquid-cooled engine that produces 60 horsepower at 2100 rpm. The tractor operates with a mechanical steering system, and is built upon a 4x2 2WD chassis. It has an 8-speed manual transmission capable of shifting into 8 forward gears and 2 reverse gears. The oil bath air cleaner and a high engine compression ratio of 17.4:1 suggest the tractor is intended for use in environments with a lot of dust and air particulates. With a notable ground clearance of 16.1 inches, it provides good operational capabilities on varied terrains. Weighing 5,182 pounds, and with dimensions of 148.1 inches in length, 72.4 inches in width, and 92.9 inches in height, the DI-90 is a robust tractor that balances size and power.
Show more...

Key Specifications

Power Output: 60

Transmission: Manual

Drive Type: 2WD

Operating Weight: 5182

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Sonalika
Model
4100F
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
210.9
Bore (in)
3.937
Stroke (in)
4.331
Rated RPM
2100
Power Output (hp)
60

Transmission

Type
Manual
Forward Gears
8
Reverse Gears
2
Total Gears
10

Dimensions

Length (in)
148.1
Width (in)
72.4
Height (in)
92.9
Operating Weight (lb)
5182

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Mechanical
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category 2
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
