Shibaura V450F

Last Updated: June 2024

Overview

The Shibaura V450F is a 4-wheel drive utility tractor equipped with a Shibaura diesel engine producing 50 horsepower. The tractor features a liquid-cooling system, a power steering system, and an electric starter. It operates with a 24-speed synchromesh transmission offering a variety of gears for diverse tasks. The chassis consists of a 4x4 MFWD 4WD configuration, indicative of its capability to handle a range of conditions. The tractor has a solid operating weight of 4630 lbs, which hints at its stability and strength for work in utility roles. It stands 96.5 inches tall at the exhaust and offers significant ground clearance of 14.4 inches. This model's dimensions and weight suggest it is designed to provide robust performance for agricultural tasks.

Key Specifications

Category: Utility

Power Output: 50

Transmission: Synchromesh

Drive Type: 4WD

Operating Weight: 4630

Fuel Type: Diesel

Image Gallery

Shibaura V450F Tractor

Shibaura V450F vs. Similar Tractors

Power Output

Average

Greater than 49% of similar tractors.

Operating Weight

Average

Greater than 41% of similar tractors.

Technical Specifications

Engine

Manufacturer: Shibaura
Model: S4F7
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural
Cylinders: 4
Displacement (ci): 166
Bore (in): -
Stroke (in): -
Rated RPM: 2500
Power Output (hp): 50

Transmission

Type: Synchromesh
Forward Gears: 24
Reverse Gears: 24
Total Gears: 48

Dimensions

Length (in): 140.2
Width (in): 65.8
Height (in): 96.5 (to exhaust)
Operating Weight (lb): 4630

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): 9
Front Tire Diameter (in): 20
Front Tire Width (in): 9.5
Rear Tire Diameter (in): 32
Rear Tire Width (in): 12.4
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: I
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
