Shibaura SF1000T

Last Updated: June 2024

Overview

The Shibaura SF1000T is a tractor that boasts a powerful 105 hp, Shibaura turbocharged diesel engine, making it capable of handling various agricultural tasks efficiently. Its engine, model LER1104T, is liquid-cooled to maintain optimal operating temperatures during long working hours. The tractor comes equipped with a constant mesh transmission, offering a substantial number of gears, with 16 forward and 4 reverse speeds. This allows for flexibility in speed selection to match a wide range of tasks. The tractor's standard agricultural tires are sized at 8.25-20 for the front and 18.4-34 for the rear, contributing to its sturdy grip on farming terrain. Its substantial operating weight is approximately 7408 lbs, which gives it stability and traction when performing heavy-duty tasks. The Shibaura SF1000T is designed considering practical dimensions with a length of 157.9 inches and a height of 72.4 inches to the steering wheel, which should be comfortable for operators. This model operates with an electric starter and benefits from an open center hydraulic system type.
Show more...

Key Specifications

Power Output: 105

Transmission: constant mesh

Operating Weight: 7408

Fuel Type: diesel

Technical Specifications

Engine

Manufacturer
Shibaura
Model
LER1104T
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
turbocharged
Cylinders
4
Displacement (ci)
278.3
Bore (in)
4.331
Stroke (in)
4.724
Rated RPM
2200
Power Output (hp)
105

Transmission

Type
constant mesh
Forward Gears
16
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
157.9
Width (in)
79.7
Height (in)
72.4 (to steering wheel)
Operating Weight (lb)
7408

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 2
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
electric
Brake Type
-
Hydraulic System Type
open center
