Shibaura SE3040

Last Updated: June 2024

Overview

The Shibaura SE3040 is a compact utility tractor designed for various agricultural and landscaping functions. It features a four-wheel-drive chassis (4x4 MFWD 4WD) which, combined with a Shibaura LEM853 diesel engine, provides reliable performance and durability in different working conditions. The tractor comes equipped with a 12-speed gear transmission type, offering 12 forward and 4 reverse gears, which accommodates a range of tasks and terrain types. The engine offers a power output of 30 horsepower with three cylinders and a displacement of 87.2 cubic inches. It operates efficiently within an RPM range of 1400 to 2800, with a rated RPM of 2800, delivering enough torque for various applications. The tractor's liquid-cooled engine system ensures long-lasting operation and managing engine temperatures effectively. With a weight of 2568 pounds and a substantial ground clearance of 13.8 inches, the SE3040 can navigate and work in diverse environments, while its dimensions provide a good balance between maneuverability and stability.
Show more...

Key Specifications

Category: Utility

Power Output: 30

Transmission: Gear

Drive Type: 4WD

Operating Weight: 2568

Fuel Type: Diesel

Shibaura SE3040 vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.
Operating Weight
Below Average
Greater than 20% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
LEM853
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
87.2
Bore (in)
3.35
Stroke (in)
3.31
Rated RPM
2800
Power Output (hp)
30

Transmission

Type
Gear
Forward Gears
12
Reverse Gears
4
Total Gears
16

Dimensions

Length (in)
118.9
Width (in)
62.2
Height (in)
59.8 (steering wheel height)
Operating Weight (lb)
2568

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
16/24
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric starter
Brake Type
-
Hydraulic System Type
Open Center
