Shibaura 1210

Last Updated: June 2024

Overview

The Ford 1210 is a versatile compact utility tractor that was produced by Shibaura for the Ford brand as part of the Ten compact series from 1983 to 1986. It comes with either 2WD or optional 4WD and a sturdy 3-cylinder Shibaura S723 diesel engine with a displacement of 53.6 cubic inches. Manual steering and a variety of transmission options—including gear shift with 10 forward and 2 reverse gears, hydrostatic, and a creeper variant—make it adaptable to various tasks. The tractor is designed to handle attachment options and comes equipped with a Category I three-point hitch with a lift capacity of 881 pounds and an option for middle or front PTOs. Its liquid-cooled engine delivers 16 horsepower and operates at a rated RPM of 2700. Safety features, such as the rollover protection structure (ROPS), reflect its design focus on operator safety. The Ford 1210 fits well into a lifestyle of small-scale farming or robust yard maintenance.
Show more...

Key Specifications

Category: Utility

Power Output: 16

Transmission: Gear shift, Hydrostatic (optional), Creeper (optional)

Operating Weight: 1329 (2WD), 1442 (4WD)

Fuel Type: Diesel

Lift Capacity: 881 lbs

Shibaura 1210 vs. Similar Tractors

Power Output
Poor
Greater than 4% of similar tractors.
Hitch Capacity
Below Average
Greater than 18% of similar tractors.
Operating Weight
Average
Greater than 66% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
S723
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
53.6
Bore (in)
2.83
Stroke (in)
2.83
Rated RPM
2700
Power Output (hp)
16

Transmission

Type
Gear shift, Hydrostatic (optional), Creeper (optional)
Forward Gears
10 (Gear shift), Infinite (2-range) (Hydrostatic), 15 (Creeper)
Reverse Gears
2 (Gear shift), Infinite (Hydrostatic), 3 (Creeper)
Total Gears
-

Dimensions

Length (in)
101
Width (in)
43.3
Height (in)
50.4 (steering wheel), 79.5 (ROPS)
Operating Weight (lb)
1329 (2WD), 1442 (4WD)

Power Take-Off (PTO)

PTO Type
Rear, Middle (optional), Front (optional)
PTO Speed 1 (rpm)
540 (Rear)
PTO Speed 2 (rpm)
1000 (Middle)
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4×2 2WD or 4×4 MFWD 4WD (optional)
Drive Type
-
Steering Type
Manual
Coolant Capacity (qts)
2.5
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (agricultural), Turf/Lawn
Manufacture - End Year
1986
Hitch Type
Three-point hitch
Hitch Category
Category I
Hitch Position
Rear
Hitch Capacity (lb)
881 lbs
Operator Station Type
ROPS (open)
Starter Type
Electric starter
Brake Type
Differential mechanical drum
Hydraulic System Type
Open center
