Schluter Super 1250

Last Updated: June 2024

Overview

The Schluter Super 1250 is a tractor designed primarily for agricultural purposes. It features a 4x2 2WD chassis indicating that it has four wheels with two-wheel drive functionality. The tractor comes equipped with a 115 horsepower 6-cylinder engine made by Schluter itself, and bears the engine model designation SDM 110 W 6. With a 12-speed manual transmission, it offers 12 forward and 6 reverse gears, providing the operator with a variety of speed options for different working conditions. It operates at a rated 1800 RPM with a torque output of 340.8 lb-ft at 1300 RPM. Supportive of power steering, it eases the physical effort required to maneuver the tractor. It has a listed operating weight of 9415 pounds and dimensions that ensure stability and functionality in the field. The tire specifications suggest it uses agricultural type tires, suited for traction and durability in farming activities. While the Super 1250's exact category and several other features are not fully detailed in the data provided, the tractor embodies essential characteristics that facilitate mid-sized farming operations.
Show more...

Key Specifications

Power Output: 115

Transmission: Manual

Drive Type: 2WD

Operating Weight: 9415

Technical Specifications

Engine

Manufacturer
Schluter
Model
SDM 110 W 6
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
-
Cylinders
6
Displacement (ci)
434.9
Bore (in)
4.331
Stroke (in)
4.921
Rated RPM
1800
Power Output (hp)
115

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
6
Total Gears
18

Dimensions

Length (in)
172.8
Width (in)
-
Height (in)
98.8
Operating Weight (lb)
9415

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
6.5
Rear Tire Diameter (in)
-
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
