Schluter Compact 1150 TV 6

Last Updated: June 2024

Overview

The Schluter Compact 1150 TV 6 is a 4-wheel drive tractor, designed with a 4x4 MFWD 4WD chassis for improved traction and performance in various field operations. It operates with a hydraulic power steering system that facilitates ease of maneuverability. This model is equipped with a robust and reliable MAN turbo diesel engine, model D 0226 MTE 51, featuring 6 cylinders and a displacement of 347.0 cubic inches. The engine boasts 110 horsepower at 2200 RPM and a torque of 315.7 lb-ft at 1300 RPM. The tractor's manual transmission provides 12 forward and 5 reverse gears, giving the operator a wide range of speeds suitable for different tasks. Additionally, the tractor measures 164.2 inches in length and stands 106.7 inches tall, with an operating weight of 10,848 lbs. The Schluter Compact 1150 TV 6 is equipped with agricultural tires, with front and rear sizes of 12.4R28 and 18.4R38 respectively. This tractor's combination of power, versatility, and durability makes it suitable for a variety of agricultural operations.
Show more...

Key Specifications

Power Output: 110

Transmission: Manual

Drive Type: 4WD

Operating Weight: 10,848

Fuel Type: Turbo diesel

Technical Specifications

Engine

Manufacturer
MAN
Model
D 0226 MTE 51
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbo diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
347
Bore (in)
4.016
Stroke (in)
4.567
Rated RPM
2200
Power Output (hp)
110

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
5
Total Gears
-

Dimensions

Length (in)
164.2
Width (in)
-
Height (in)
106.7
Operating Weight (lb)
10,848

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
