SAME Titan 190

Last Updated: June 2024

Overview

The SAME Titan 190 is a robust row-crop tractor known for its powerful 189 horsepower turbocharged diesel engine. With a liquid-cooling system, it ensures reliable performance during long hours of operation. The engine displaces 366.1 cubic inches and operates at a rated RPM of 2350, signifying its capability to handle demanding tasks. The chassis features 4x4 MFWD 4WD, making it well-suited for various terrains and agricultural operations. The tractor is equipped with a 27-speed power shift transmission, providing a range of speed options for different working conditions. While the exact cylinder orientation and valve configuration remain unknown, the tractor’s engineering emphasizes efficient operation and durability. The weight of the Titan 190 is substantial, coming in at 13,671 pounds, contributing to its stability and traction capability. Although certain specifications such as PTO speed and hydraulic system type are not provided, this tractor remains a significant asset for farmers seeking a reliable machine for heavy-duty farming tasks.
Show more...

Key Specifications

Category: Row Crop

Power Output: 189

Transmission: Power shift

Drive Type: 4WD

Operating Weight: 13671

Fuel Type: Diesel

SAME Titan 190 vs. Similar Tractors

Power Output
Average
Greater than 69% of similar tractors.
Operating Weight
Average
Greater than 55% of similar tractors.

Technical Specifications

Engine

Manufacturer
SAME
Model
1000.6 WTIR
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
366.1
Bore (in)
4.134
Stroke (in)
4.54
Rated RPM
2350
Power Output (hp)
189

Transmission

Type
Power shift
Forward Gears
27
Reverse Gears
27
Total Gears
-

Dimensions

Length (in)
187
Width (in)
92.9
Height (in)
114.2 (height with cab)
Operating Weight (lb)
13671

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Hitch Position | Unknown
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
