SAME Krypton F 100

Last Updated: June 2024

Overview

The SAME Krypton F 100 is a machine designed to meet tough working conditions with its robust features. This tractor is powered by a SAME 1000.4 WT, 4-cylinder, liquid-cooled, turbocharged diesel engine with a displacement of 244.1 cubic inches. It delivers a rated power of up to 93.7 horsepower, achieving its peak torque of 278 lb-ft at just 1400 RPM. The drivetrain of the Krypton F 100 consists of a shuttle and creeper transmission, offering 16 forward and reverse gears, suitable for a range of tasks requiring precision and variable speeds. This tractor can operate efficiently for extended hours thanks to a rated 2200 RPM engine speed. With a length of 129.9 inches and a height of 56.3 inches, the vehicle's dimensions and an operating weight of 9150 lbs contribute to its stability and capacity for heavy-duty operations. While some specifics like the chassis type, PTO details, and additional features are not provided, this tractor's primary specifications indicate a reliable and potent machine for agriculture or heavy-duty applications.
Show more...

Key Specifications

Power Output: 93.7 (Using the highest reported power from the Engine - Rated Power 2000/25/CE)

Transmission: Shuttle, Creeper

Operating Weight: 9150

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
SAME
Model
1000.4 WT
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
244.1
Bore (in)
4.13
Stroke (in)
4.55
Rated RPM
2200
Power Output (hp)
93.7 (Using the highest reported power from the Engine - Rated Power 2000/25/CE)

Transmission

Type
Shuttle, Creeper
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
129.9
Width (in)
Unknown (Width specs given were inconsistent and likely not the overall width)
Height (in)
56.3
Operating Weight (lb)
9150

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
