SAME Explorer 55

Last Updated: June 2024

Overview

The SAME Explorer 55 is a utility tractor designed primarily for use in a wide range of agricultural tasks. It is equipped with a SAME 3-cylinder diesel engine that provides 55 horsepower and is air-cooled. With an engine displacement of 167.8 cubic inches and a rated RPM of 2500, this model is capable of handling various farming implements and operations. The Explorer 55 features a power steer system and a 15-speed transmission with equal numbers of forward and reverse gears, facilitating ease of operation in different field conditions. The chassis configuration of this tractor is a 4x2 2WD, which, combined with a dry air cleaner and a 12-volt electric starter, suggests a tractor that balances performance and simplicity. Weighing between 5986 and 6515 pounds, this tractor maintains a sturdy presence on fields with dimensions measuring 151.18 inches in length and 98.82 inches in height. Traditional agricultural tires—size 7.50-16 in the front and 14.9-30 in the rear—complement the utilitarian design of the Explorer 55.
Show more...

Key Specifications

Category: Utility

Power Output: 55

Drive Type: 2WD

Operating Weight: 5986 to 6515

Fuel Type: Diesel

SAME Explorer 55 vs. Similar Tractors

Power Output
Average
Greater than 53% of similar tractors.
Operating Weight
Above Average
Greater than 89% of similar tractors.

Technical Specifications

Engine

Manufacturer
SAME
Model
-
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
167.8
Bore (in)
4.06
Stroke (in)
4.33
Rated RPM
2500
Power Output (hp)
55

Transmission

Type
-
Forward Gears
15
Reverse Gears
15
Total Gears
30

Dimensions

Length (in)
151.18
Width (in)
-
Height (in)
98.82
Operating Weight (lb)
5986 to 6515

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
