SAME Dorado 70

Last Updated: June 2024

Overview

The SAME Dorado 70 is a versatile tractor suitable for a variety of farming tasks. It is characterized by a simple 4x2 2WD chassis, indicating that it has four wheels with two driving wheels, which is sufficient for operations on terrain where four-wheel drive isn't necessary. The tractor comes with a turbocharged diesel engine that either has three or four cylinders, and may displace either 183.1 or 244 cubic inches. The bore and stroke are 4.134 and 4.54 inches respectively. The SAME Dorado 70 features quite a broad and intricate transmission, with up to 30 forward and 15 reverse gears. This indicates it is able to provide the operator with great flexibility in speed and power manageability. With operating weights reported as 5865 or 4454 lbs, and different reported wheelbases, it might suggest there were different configurations or updates throughout its production. However, specific years of manufacture are unknown, which could give a more precise insight into these disparities. The tractor features a Category 3 hitch at the rear, making it capable of working with a wide range of implements.
Show more...

Key Specifications

Power Output: 67 or 70

Drive Type: 2WD

Operating Weight: 5865 or 4454

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
SAME
Model
-
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3 or 4
Displacement (ci)
183.1 or 244
Bore (in)
4.134
Stroke (in)
4.54
Rated RPM
2200 or 2350
Power Output (hp)
67 or 70

Transmission

Type
-
Forward Gears
30
Reverse Gears
15
Total Gears
-

Dimensions

Length (in)
151.57 or 114.57
Width (in)
-
Height (in)
95.28 or 88.58
Operating Weight (lb)
5865 or 4454

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
