SAME Dorado 100

Last Updated: June 2024

Overview

The SAME Dorado 100 is a 4x4 MFWD 4WD tractor that offers a blend of performance and practicality. Equipped with a SAME turbo diesel engine, it delivers 90 horsepower while operating at 2200 RPM. The tractor's power is managed through a transmission system that provides 16 forward gears and 8 reverse gears, enabling it to handle a variety of tasks with ease. The Dorado 100's chassis is robust, with a wheelbase of 81.10 inches, contributing to its stability. With an operating weight of 5446 lbs, the tractor is designed to perform a range of agricultural duties. The dimensions of the tractorincluding a length of 121.65 inches and a height of 90.55 inchesindicate a relatively compact design that maintains efficient maneuverability in different farm applications. The tractor's rear tires are specified as 420/70R24, which is typically a size well-suited for tasks requiring a combination of traction and comfort. The SAME Dorado 100 falls into the general-purpose segment of farm tractors, capable of handling utility tasks in crop production, among various other duties.
Show more...

Key Specifications

Power Output: 90

Drive Type: 4WD

Operating Weight: 5446

Fuel Type: Turbo Diesel

Technical Specifications

Engine

Manufacturer
SAME
Model
-
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbo Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
244.08
Bore (in)
-
Stroke (in)
-
Rated RPM
2200
Power Output (hp)
90

Transmission

Type
-
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
121.65
Width (in)
-
Height (in)
90.55
Operating Weight (lb)
5446

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
24 (Based on tire specification 420/70R24)
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
