SAME Corsaro 70

Last Updated: June 2024

Overview

The SAME Corsaro 70 is a utility tractor that was designed with a 4x2 two-wheel drive chassis and manual steering. It features a manual transmission with a creeper gear, including 14 forward and 7 reverse gears, to handle a variety of tasks. This workhorse is powered by a SAME 984 P diesel engine with an air-cooling system and direct injection, providing 68.4 horsepower at a rated RPM of 2200. As indicated by its model, the engine displacement is about 220.89 cubic inches with a bore and stroke of 3.86 inches by 4.72 inches respectively. The Corsaro 70 supports various tire configurations and shows adaptability with its optional ag tires. While dimensions vary slightly between the 2WD and 4WD models, the tractor generally maintains a footprint with a 74-inch width and lengths of 153.5 inches and 154.7 inches for the 2WD and 4WD versions respectively. The weight also varies depending on the drivetrain, with the 2WD model weighing in at 5908 lbs and the 4WD heavier at 6460 lbs. It comes standard with a Category II three-point hitch system, accommodating a range of attachments and implements for agricultural operations.
Show more...

Key Specifications

Power Output: 68.4

Transmission: Manual with creeper

Drive Type: 2WD

Operating Weight: 5908 (2WD) / 6460 (4WD)

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
SAME
Model
984 P
Cooling Type
Air
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspiration with direct injection
Cylinders
4
Displacement (ci)
220.89
Bore (in)
3.86
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
68.4

Transmission

Type
Manual with creeper
Forward Gears
14
Reverse Gears
7
Total Gears
-

Dimensions

Length (in)
153.5 (2WD) / 154.7 (4WD)
Width (in)
74
Height (in)
68.4 (2WD hood) / 53.2 (4WD hood) / 94.1 (ROPS)
Operating Weight (lb)
5908 (2WD) / 6460 (4WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
Category II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
