Renault 921S

Last Updated: June 2024

Overview

The Renault 921S is a robust and versatile tractor known for its 4-wheel drive capability through a 4x4 MFWD chassis configuration. Equipped with a 12-speed manual transmission and hydrostatic power steering, it provides a balance of control and power. The heart of the 921S is an MWM D227-6 diesel engine with 6 cylinders, producing 92 horsepower and a displacement of 345.1 ci. This tractor also features a substantial operating weight of 10,849 pounds, indicating its suitability for heavier work demands. With a reported torque of 248.6 lb-ft at 1100 RPM and an engine rated at 2350 RPM, the 921S provides ample power for a variety of tasks, from tilling to hauling. Tire sizes are specified as 14.9-24 in the front and 16.9-38 in the rear, complementing its four-wheel drive to ensure strong traction in diverse field conditions. The tractor's dimensions, including a length of 174.8 inches and height of 109.1 inches, contribute to its stability and presence on the field. An estimated wheelbase of 105.5 inches also supports better maneuverability.
Show more...

Key Specifications

Power Output: 92

Transmission: Manual

Drive Type: 4WD

Operating Weight: 10849

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
MWM
Model
D227-6
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
6
Displacement (ci)
345.1
Bore (in)
3.875
Stroke (in)
4.724
Rated RPM
2350
Power Output (hp)
92

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
174.8
Width (in)
-
Height (in)
109.1
Operating Weight (lb)
10849

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24
Front Tire Width (in)
14.9
Rear Tire Diameter (in)
38
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
