Renault 75-32 TX

Last Updated: June 2024

Overview

The Renault 75-32 TX is a 2WD utility tractor that was produced by Renault between 1989 and 1993. It is equipped with a four-cylinder MWM D226-4 diesel engine featuring a liquid cooling system and a natural aspiration. With a displacement of 4.2 liters, it generates 70 horsepower at 2350 RPM and 177 lb-ft of torque at 1500 RPM. The tractor features a manual transmission with 12 forward and reverse gears and operates on a 2WD chassis. For steering comfort, the tractor utilizes power steering, and it is equipped with wet disc brakes for effective stopping power. It has a standard cab for operator protection and comfort. The tractor has a wheelbase of 95.7 inches, and it weighs 7,342 pounds with operating capabilities supported by an 8,269-pound hitch lift capacity. Tires installed are agricultural type with sizes 7.50-18 for the front and 16.9-34 for the rear. The Renault 75-32 TX, with its robust build and reliable engine, is suited for a variety of utility tasks on the farm.
Show more...

Key Specifications

Category: Utility

Power Output: 70

Transmission: Manual

Drive Type: 2WD

Operating Weight: 7,342

Fuel Type: Diesel

Renault 75-32 TX vs. Similar Tractors

Power Output
Average
Greater than 64% of similar tractors.
Hitch Capacity
Below Average
Greater than 12% of similar tractors.
Operating Weight
Poor
Greater than 4% of similar tractors.

Technical Specifications

Engine

Manufacturer
MWM
Model
D226-4
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
253.6
Bore (in)
4.134
Stroke (in)
4.724
Rated RPM
2350
Power Output (hp)
70

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
154.3
Width (in)
-
Height (in)
109.1
Operating Weight (lb)
7,342

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
1000
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
1993
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
8,269
Operator Station Type
Cab
Starter Type
Electric
Brake Type
Wet disc
Hydraulic System Type
-
