Renault 50-12 LB

Last Updated: June 2024

Overview

The Renault 50-12 LB is a utility tractor that is well-suited for various agricultural tasks. It is powered by a 44.3 horsepower Deutz F3 L 912 engine, which is a 3-cylinder, air-cooled, diesel unit that provides a good balance between performance and efficiency. The engine's displacement is 172.5 cubic inches, and it operates at a rated RPM of 2350, delivering a torque of 113.6 lb-ft at 1600 RPM. This tractor features a 4x2 2WD chassis with power steering, facilitating maneuverability on the farm. Transmission-wise, it is equipped with an 8-speed gearbox with a mechanical shuttle, providing the same number of gears for forward and reverse movement. The tractor rides on agricultural tires, with front tread adjustable between 51.2 to 74.8 inches and the same range for the rear, allowing for stability and good traction across a variety of field conditions. In terms of dimensions, the tractor has a length of 129.9 inches, a width of 64.6 inches, and variable height depending on the presence of ROPS (88.6 inches) or a cab (87 inches). It carries an operating weight of 4630 pounds and can handle a maximum weight of 9392 pounds. The Renault 50-12 LB tractor offers a reliable power source and the essential features needed for diverse farming operations.
Show more...

Key Specifications

Category: Utility

Power Output: 44.3

Transmission: Mechanical shuttle

Drive Type: 2WD

Operating Weight: 4630

Fuel Type: Diesel

Renault 50-12 LB vs. Similar Tractors

Power Output
Average
Greater than 41% of similar tractors.
Operating Weight
Average
Greater than 41% of similar tractors.

Technical Specifications

Engine

Manufacturer
Deutz
Model
F3 L 912
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
172.5
Bore (in)
3.875
Stroke (in)
4.724
Rated RPM
2350
Power Output (hp)
44.3

Transmission

Type
Mechanical shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
129.9
Width (in)
64.6
Height (in)
88.6 (ROPS), 87 (cab)
Operating Weight (lb)
4630

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
