Renault 461S

Last Updated: June 2024

Overview

The Renault 461S is a utility tractor, designed for a variety of tasks in agricultural settings. This model is equipped with a 46 horsepower, air-cooled, naturally aspirated MWM D327-3 diesel engine, offering a displacement of 172.5 cubic inches. The engine's bore and stroke measurements are 3.875 inches and 4.724 inches respectively, with a compression ratio of 17.6:1. It operates at a rated rpm of 2150 and develops a torque of 129.1 lb-ft at 1500 rpm. The tractor's chassis is a 4x2 2WD configuration with power steering and a 10-speed manual transmission, including 10 forward and 2 reverse gears. The tractor's wheelbase is 82.7 inches, allowing for a stable ride, and the total length is 135.8 inches. The 461S features a dual-choice operator station, offering a cabin for protection from the elements or a ROPS (Roll-Over Protective Structure) for safety in open-air operation. It has an operating weight of 5081 pounds when equipped with the cab. Tire sizes for the agricultural front and rear tires vary with two sets of measurements provided, potentially indicating optional sizes. The standard three-point hitch on this model is a Category I, suitable for a variety of implements. Details on hitch lift capacity, PTO speeds, brake type, and hydraulic flow rates are not provided. The Renault 461S is a robust and versatile tractor, ideal for farmers in need of a reliable utility tractor for diverse agricultural tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 46

Transmission: Manual

Drive Type: 2WD

Operating Weight: 5081 (with cab)

Fuel Type: Diesel

Renault 461S vs. Similar Tractors

Power Output
Average
Greater than 44% of similar tractors.
Operating Weight
Average
Greater than 43% of similar tractors.

Technical Specifications

Engine

Manufacturer
MWM
Model
D327-3
Cooling Type
Air-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
172.5
Bore (in)
3.875
Stroke (in)
4.724
Rated RPM
2150
Power Output (hp)
46

Transmission

Type
Manual
Forward Gears
10
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
135.8
Width (in)
66.9
Height (in)
92.9 (highest point with cab)
Operating Weight (lb)
5081 (with cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab, ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
